Construction:
Tube: Oil resistant synthetic rubber
Reinforcement: One fiber braid
Cover: Oil and weather resistant synthetic rubber
Temperature: -40°C to +100°C
Application: Petroleum based hydraulic fluid, gasoline, water, lubricating oils, glycol, mineral oils, and more
| Size | SAE | Inside
Ø mm |
Outside
Ø mm |
Working
Pressure |
Burst
Pressure |
Bend Radius | Length | Weight | |||||
| mm | inch | Dash | Min | Max | Max | Bar | Psi | Bar | Psi | mm | m | Kg/m | |
| 5 | 3/16 | -03 | 4.5 | 5.4 | 10.3 | 11.1 | 34 | 500 | 138 | 2000 | 50 | 50/100 | 0.11 |
| 6.3 | 1/4 | -04 | 6.1 | 7.0 | 11.9 | 12.7 | 28 | 400 | 110 | 1600 | 65 | 50/100 | 0.15 |
| 8 | 5/16 | -05 | 7.6 | 8.5 | 13.5 | 14.3 | 28 | 400 | 110 | 1600 | 75 | 50/100 | 0.16 |
| 10 | 3/8 | -06 | 9.2 | 10.1 | 15.1 | 15.9 | 28 | 400 | 110 | 1600 | 75 | 50/100 | 0.18 |
| 12.5 | 1/2 | -08 | 12.4 | 13.5 | 19.0 | 19.8 | 28 | 400 | 110 | 1600 | 100 | 50/100 | 0.26 |
| 16 | 5/8 | -10 | 15.6 | 16.7 | 22.2 | 23.0 | 24 | 350 | 97 | 1400 | 125 | 50/100 | 0.29 |
| 19 | 3/4 | -12 | 18.7 | 19.8 | 25.4 | 26.6 | 21 | 300 | 83 | 1200 | 150 | 50/100 | 0.40 |
